Enhance your machine with the addition of two momentary controls using our innovative solution, designed specifically for older machines such as Cat (A, B, or C Series), ASV, or Terex models featuring an 8-pin output with only 4 available switches. This upgrade is also ideal for Kubota machines with a 14-pin connector but only 4 active pins, as well as Takeuchi and other older equipment that typically offer just 4 control buttons. For CAT D-Series machines with low flow, this product saves you from the costly addition of extra switches after purchase.
Bring exceptional functionality and ease to your operations with this straightforward installation. Secure the user-friendly toggle switch inside your cab using the provided self-tapping screws to firmly attach the bracket to your machine's frame. Simply connect the power wire to a 12-volt source within your cab. The pair of output wires, extending 25 feet, can be routed from your cab to the boom. For optimal protection, guide the wires alongside your hydraulic lines and secure them with tie wraps.
This practical solution reflects the Skid Steer Genius ingenuity, providing an effective and economical way to upgrade your machinery's control capabilities.
There are two ways to install this kit.
1: Use it as is and with the added plug to your wiring you can just operate the attachment as needed.
2: You can use this to add 2 controls to your machine to work in conjunction with your other controls by doing the following.
Here's how:
1: Install the control and cable into the cab and run the extension wire out the boom to your existing 14 pin cable.
2: Open up the back of your 14 pin connector and slide the two pinned wires into unused positions in the connector.
3: Match your attachment pinning to these positions how you want it to operate and you should be good to go.
No videos available for this product yet.
This control upgrade is designed to add two momentary control functions to older machines that are limited to only four factory-installed controls.
It is intended for older Cat A, B, and C Series machines, ASV and Terex models with 8-pin connectors, as well as Kubota, Takeuchi, and other machines with limited active pins in a 14-pin connector.
Many older machines only include four control buttons, making it difficult to operate modern attachments. This solution adds two additional controls without requiring expensive factory upgrades.
The toggle switch is mounted inside the cab using the included bracket and self-tapping screws, securing it firmly to the machine frame.
The control kit is powered by connecting a wire to a 12-volt power source inside the cab.
The output wires extend up to 25 feet and are routed from the cab along the boom, typically secured alongside hydraulic lines using tie wraps.
Yes, it can be used as a standalone control to operate attachments independently without modifying the machine’s existing wiring.
Yes, it can be integrated by inserting the two control wires into unused pin positions in the machine’s connector, allowing the new controls to function alongside existing ones.
On 14-pin machines, the additional control wires are inserted into unused pin positions. On 8-pin machines, the extra control wires remain external and connect using a separate two-pin connector.
This product avoids the need for factory-installed switches or expensive control modules, offering a simple and economical way to expand control capability.
