Vendor: WAIN ROY
SKU: CFX450DB48
Availability: In stock
$10,776.99
$11,853.99
$10,776.99
Style: Standard Capacity
SIZE: 48"
Subtotal: $10,776.99

Free Shipping

This product is eligible for Free Shipping!
Ditching & Grading Buckets for 95,000-110,000 lbs. Excavators - WAIN ROY

Ditching & Grading Buckets for 95,000-110,000 lbs. Excavators - WAIN ROY

$11,853.99 $10,776.99
Ditching & Grading Buckets for 95,000-110,000 lbs. Excavators - WAIN ROY
Ditching & Grading Buckets for 95,000-110,000 lbs. Excavators - WAIN ROY-1
Ditching & Grading Buckets for 95,000-110,000 lbs. Excavators - WAIN ROY-2
Ditching & Grading Buckets for 95,000-110,000 lbs. Excavators - WAIN ROY-3

Ditching & Grading Buckets for 95,000-110,000 lbs. Excavators - WAIN ROY

$11,853.99 $10,776.99
Style: Standard Capacity
SIZE: 48"
Description

Shop the Ditching & Grading Buckets for 95,000-110,000 lbs. Excavators - WAIN ROY

Description:

CFX450DB / CFX455DB
STANDARD/HIGH CAPACITY DITCH CLEANING PIN-ON EXCAVATOR BUCKET
Ditching & Grading Buckets are used for ditch cleaning, grading, backfilling and loose material loading applications. They feature a wide and shallow tub design that offers a shorter tip radius allowing for the increased width without losing material penetration. Ditching & Grading buckets are ideal for use in sand, topsoil, and other loose or soft materials.

AVAILABLE MOUNTS

AVAILABLE MOUNTS DESCRIPTION
OEM PIN ON TWO HORIZONTAL PINS

Specifications:

DITCH CLEANING STD. CAPACITY - CFX450DB
Bucket Width Capacity (Cu. Yd.) Weight (LBS)
48" 1.28 1846
54" 1.47 1996
60" 1.65 2145
66" 1.84 2296
72" 2.02 2445
78" 2.21 2595
84" 2.39 2862
96" 2.57 3171


DITCH CLEANING HIGH CAPACITY - CFX455DB
Bucket Width Capacity (Cu. Yd.) Weight (LBS)
48" 1.44 2104
54" 1.64 2265
60" 1.85 2423
66" 2.06 2584
72" 2.27 2742
78" 2.47 2902
84" 2.68 3193
96" 2.79 3513

Fits:

MAKE MODELS (95,000 - 110,000 LBS)
CASE CX460, CX460 EXT, CX470B, CX490D
CAT 345C L, 345C L WVG, 345C L WVGLR, 345C LR, 345C VG, 345D L, 349F L (2017), 349F L XE (2017), 352F, TB-link
DOOSAN DX420LC, DX420LC-5, DX480LC, DX480LCRCW, S470LCV, S470LCVLF
HITACHI EX400, ZX450KC ME, ZX450LC, ZX450LC-3, ZX470
HYUNDIA R450LC-7, R480LC-9, R480LC-9A
JCB JS460, JS460LC
JOHN DEERE 450C LC, 470G LC, 992D, 992E
KOBELCO SK480LC-DA, SK480LC-ME
KOMATSU PC400LC-6, PC400LC-7, PC400LC-8, PC450-6, PC450-7, PC450LC-6, PC450LC-8, PC490LC-11, PC490LCi-11
LIEBHERR R944C, R944C Tunnel Litronic, R946 Litronic, R950 Tunnel Litronic, R954B, R954B-V, R954C
LINK-BELT 460 X2, 460LX
LIUGONG CLG950E
TEREX TXC470LC, TXC480LC-2
VOLVO EC460B-icme, EC460B-LC, EC460C, EC480E
