Recommended flow
10-36 GPM
Torque @ 3,000 PSI
5,012 ft-lbs
Model
6DDT
Guaranteed Fit
Fast Shipping
Hassle-Free Returns
Description
Made in USA
5-yr warranty
Overview
The middle model of three two-speed drives on the 2.5" hex shaft, this 2 speed auger drive sits between the 5DDT and 7DDT and asks for more flow than the 5DDT to reach its higher torque. All three shift between a high-torque and a high-speed range, all three need a case drain, and all three take the same A6, RC6 and DR6 auger bits — so the choice between them comes down entirely to what your machine’s hydraulics can deliver.
Key Features of the 6DDT 2 Speed High Flow Auger Drive
- 5,012 ft-lbs of torque — the figure Digga publishes for the 6DDT
- 10-36 GPM recommended flow — match this against your carrier’s auxiliary circuit
- 2.5" Hex output shaft — sets which Digga auger bits fit
- Compact high torque Digga gearbox
- Fitted with high efficiency Eaton VIS motor and 3 year motor warranty
- TRU-CUT – a 12†auger cuts a 12†hole, no more oversized holes!
- Over 40 years of auger design and manufacture has resulted in an extremely efficient cutting head design and optimum flight pitches to provide maximum soil removal in all ground conditions.
- Made in the USA
- Easy knock in and out teeth requires no special tools
- Fitted with ECV (Energy Control Valve) to prevent rapid ENERGY CONTROL VALVE decompression of oil, caused by the reverse energy created by pile kick-back.
Why This Drive Suits Its Machine Class
- Choose by deliverable flow, not by the torque headline — a 6DDT starved of flow performs worse than a well-matched 5DDT.
- Two ranges from one drive removes the compromise a single-speed makes between turning force and rotation speed.
- Shares mounts and bits with the 5DDT and 7DDT, and with their single-speed counterparts.
- Case drain hose supplied, so the only thing your machine must have is the return line itself.
6DDT 2 Speed High Flow Auger Drive Specifications
| Specification | Value |
|---|---|
| Model | 6DDT |
| Torque @ 3,000 PSI | 5,012 ft-lbs |
| Max torque @ 3,500 PSI | 5,837 ft-lbs |
| Recommended flow | 10-36 GPM |
| Motor type | Orbital Geroler |
| Max pressure — do not exceed | 3500psi @ 27gpm |
| Max flow — do not exceed | • |
| Max horsepower | 55 HP |
| Pressure relief valve | Included |
| Standard output shaft | 2.5" Hex |
| Recommended auger bits | A6 / RC6 |
| Max drilling diameter — earth | 40" |
| Max drilling diameter — clay/shale | 30" |
| Weight | 350 lbs |
| Overall length | 34.4" |
| Diameter | 13.4" |
| HALO available | Yes |
| 5ddt | 6DDT |
| Carrier weight range | 4.5-8T (9,900-17,600 lbs) |
Every figure above is taken from Digga’s published data sheet for the 6DDT. Add your machine make and model at checkout and we confirm the fit before the order ships.
Which Machines Fit the 6DDT?
For high-flow skid steer loaders and compact track loaders with a case drain return available:
| Fitment factor | Requirement |
|---|---|
| Mount | Skid steer frame or mount, sold separately |
| Case drain | Required — hose supplied with the drive |
| Electrical | 12V for the shift solenoid via the supplied 10 ft powerlead |
| Hoses | Sold separately |
| Auger bits | Sold separately |
Bobcat
Caterpillar
John Deere
Case
New Holland
Takeuchi
Kubota
Gehl
Order online — enter your machine make and model with the order and we confirm the mount fits before it ships, coming back to you only if something needs changing. Questions first are welcome at support@eskidsteer.com or on the chat button on your screen.
6DDT 2 Speed High Flow Auger Drive Questions, Answered
When do I use high speed versus high torque on the 6DDT?
Low speed and high torque for large-diameter augers and hard fracturable rock, where turning force matters more than rotation. High speed and low torque for smaller diameters and softer soils — and for spinning spoil clear of a large auger on lift-out, which is where most of the time saving actually shows up across a day.
Does this drive require a case drain?
Yes. A two-speed drive shifts a hydraulically actuated motor and leaks internal case pressure by design. Without a dedicated low-pressure return to tank, that pressure builds against the motor shaft seal and blows it. Digga supplies the case drain hose with the drive; your machine needs the return line available.
Is the two-speed controller included?
No. The drive ships fitted with a 10-foot powerlead and two-pin connector, and controller kits are separate. Digga offers plug-and-play kits with a rocker switch and cigarette lighter lead in 10, 20, 40 and 50 foot harness lengths, plus joystick-mounted toggle and floor-mounted foot switch options.
Which of the 5DDT, 6DDT and 7DDT should I buy?
Check the flow your machine actually supplies, then take the drive whose recommended range your machine sits inside. All three share the 2.5" hex shaft, the same bit family and the same frames, so nothing is stranded either way.
What warranty applies to the 6DDT?
Five years on the gearbox and three years on the motor for drilling use, plus a lifetime shaft pull-out warranty, subject to maintenance per the operator’s manual. Digga treats anchoring separately: drives used for anchoring above 12,000 ft-lbs without an Energy Control Valve carry no warranty.
What hydraulic flow does it need?
This one is rated for 10-36 GPM. Check that figure against your machine’s auxiliary hydraulic output before choosing — a machine that cannot supply the rated flow will never reach the rated performance, and one that exceeds the limit will run the attachment hot.
Will this fit my machine?
Check three things: it is built for 4.5-8T (9,900-17,600 lbs); the interface is Skid steer frame or mount, sold separately; and it needs 10-36 GPM. Add your machine make and model at checkout and we confirm the fit before the order ships.
How is shipping calculated?
Shipping is calculated at checkout — add the item to your cart, enter your delivery address, and the shipping charge is shown before you complete your order. Lift gate service is available for residential deliveries and can be selected at checkout.
How do I order?
Add the item to your cart and check out online — the order page asks for your machine make and model, so there is no need to call ahead. We check the mount against your machine after the order and come back to you if anything needs changing. If you would rather ask first, email support@eskidsteer.com or use the chat button on your screen.
What to Order Alongside the 6DDT
- Auger bits — The 6DDT takes a 2.5" Hex output shaft, and Digga pairs it with the A6 / RC6 range.
- Mount and linkage — the 6DDT ships without one, so the interface is chosen to match your carrier rather than a generic plate.
- Hydraulic hoses and flush-face quick disconnects — sized to the 6DDT’s 10-36 GPM flow rather than to whatever is on the shelf.
- XO25 and XT25 auger extensions — cheaper than buying a longer bit for the occasional deep hole on the 6DDT, and they stack.
Contractors reach this page searching for a high flow auger drive, for a skid steer auger attachment, or specifically for a 6ddt auger drive. The 6DDT also comes up when people are comparing an auger drive against a skid steer auger, since Digga builds both on shared mounts and shared auger families. Whichever term brought you here, the 6DDT and every other digga auger drive in the range is made in Dyersville, Iowa.
