Maximum flow
80 GPM
Extension harness
10ft, 20ft, 40ft or 50ft
Compatible drives
Any, including 2-speed
Guaranteed Fit
Fast Shipping
Hassle-Free Returns
Description
Made in USA
12-mo warranty
Overview
This external 2 way flow valve kit adds forward and reverse auger rotation to a machine that only has a single-acting hammer circuit, and unlike Digga’s integrated valve it mounts to your machine rather than inside the drive. This is the 80 GPM version, for high-flow machines where the 32 GPM kit would be undersized. You choose where on the boom or stick it sits, and it can be ordered at any time — with the drive or years afterwards.
Key Features of the External 2-Way Flow Valve Kit 80GPM Max
- Maximum flow: 80 GPM
- Mounting: External — to the boom or stick of your machine
- Voltage: 12V or 24V — specified at order
- Extension harness: 10ft, 20ft, 40ft or 50ft
- The External 2-Way Flow Valve Kit (80 GPM) kit is rated to that flow as a maximum — check it against your machine’s auxiliary output before choosing.
- Mounts to your machine, not the drive, so it can be fitted at any time rather than only at drive order.
- Operator chooses the mounting position on the boom or stick.
- 12V and 24V versions, specified at order.
- Four harness lengths from 10ft to 50ft.
- Works with any drive, including the two-speed range the integrated valve cannot serve.
Why the External 2-Way Flow Valve Kit (80 GPM) Earns Its Place
- The External 2-Way Flow Valve Kit (80 GPM) exists because a single-acting hammer circuit sends oil one way only. An auger needs it both ways — forward to drill, and reverse to back out of a hole it has bound itself into. Without two-way flow, an auger caught in clay or wrapped around a root becomes a problem you solve with the machine rather than the attachment.
- An external kit stays with the machine, not the attachment — useful if one carrier runs several drives.
- It is exposed, which is the trade against the integrated valve — mount it where it will not meet trench walls or branches.
External 2-Way Flow Valve Kit 80GPM Max Specifications
| Specification | Value |
|---|---|
| Maximum flow | 80 GPM |
| Mounting | External — to the boom or stick of your machine |
| Voltage | 12V or 24V — specified at order |
| Extension harness | 10ft, 20ft, 40ft or 50ft |
| Fitted | At any time — with the drive or after-market |
| Compatible drives | Any, including 2-speed |
| Hoses | Ordered separately |
Choosing Your External 2-Way Flow Valve Kit (80 GPM)
Two decisions: your machine’s voltage, and how far the harness must run from the valve to the cab.
| Option | Choice | Notes |
|---|---|---|
| Voltage | 12V | Most compact equipment |
| Voltage | 24V | Larger excavators and many European machines |
| Extension | 10ft | Valve mounted close to the cab |
| Extension | 20ft | Typical mid-size excavator run |
| Extension | 40ft | Longer booms and larger machines |
| Extension | 50ft | Maximum reach in the range |
Voltage
- 12V
- 24V
Extension Length
- 10' Extension
- 20' Extension
- 40' Extension
- 50' Extension
Which Machines Fit the External 2-Way Flow Valve Kit (80 GPM)?
Fits any machine with a single-acting hammer circuit and no two-way hydraulic flow. Unlike the integrated valve, it works with every Digga drive including the two-speed range.
| Fitment factor | Requirement |
|---|---|
| Machine | Any carrier with a single-acting hammer circuit and no two-way flow |
| Maximum flow | 80 GPM — do not exceed |
| Electrical | 12V or 24V, specified at order |
| Drive compatibility | All Digga drives, including 2-speed |
| Mounting | Operator-installed on the boom or stick |
| Hoses | Ordered separately |
Bobcat
Caterpillar
John Deere
Case
New Holland
Takeuchi
Kubota
Gehl
Note your machine make and model at checkout and we confirm the External 2-Way Flow Valve Kit (80 GPM) suits it before the order ships.
What to Order Alongside the External 2-Way Flow Valve Kit (80 GPM)
- A cab switch — joystick-mounted toggle, floor-mounted foot switch, or the 2-way flow controller.
- Hydraulic hoses, which are not supplied with the kit.
- A longer extension harness if you later move the valve or change machines — harnesses are stocked separately in the same four lengths.
External 2-Way Flow Valve Kit 80GPM Max Questions, Answered
Is 80 GPM enough for my machine?
Check your auxiliary circuit output. Digga offers this kit at 32 GPM and 80 GPM maximum, and the valve must be rated at or above what your machine delivers. Undersizing it is not something the valve will tolerate.
External or integrated valve?
The integrated valve mounts inside the auger drive and must be ordered with the drive — it is tidier and better protected, but the window closes once the drive ships. The external kit mounts to your machine, can be fitted at any time, and works with two-speed drives which the integrated valve does not serve.
12V or 24V — which do I need?
Match your machine’s electrical system. Most compact equipment is 12V; larger excavators and some European machines are 24V. Getting this wrong means the solenoid will not switch, so check the machine rather than guessing — it is not a tolerance the valve can absorb.
Which extension length should I pick?
Measure from where the valve mounts to where the switch will sit in the cab, then add slack for boom movement and a service loop. Running out of harness is a job stopper; a coil of spare harness is only untidy. On an excavator the boom articulates through more distance than people expect, so err longer.
How is the valve operated?
By a switch in the cab. Digga offers a joystick-mounted toggle switch and a floor-mounted foot switch as separate items, plus a 2-way flow controller. Which suits you depends on whether you would rather keep a hand free or a foot free while drilling.
Will this fit my machine?
Check three things: it is built for Any carrier with a single-acting hammer circuit and no two-way flow. Add your machine make and model at checkout and we confirm the fit before the order ships.
How is shipping calculated?
Shipping is calculated at checkout — add the item to your cart, enter your delivery address, and the shipping charge is shown before you complete your order. Lift gate service is available for residential deliveries and can be selected at checkout.
How do I order?
Add the item to your cart and check out online — the order page asks for your machine make and model, so there is no need to call ahead. We check the mount against your machine after the order and come back to you if anything needs changing. If you would rather ask first, email support@eskidsteer.com or use the chat button on your screen.
Buyers find the External 2-Way Flow Valve Kit (80 GPM) searching for a auger drive valve, a flow reversal valve, or a excavator auger drive to suit a machine they already run. It sits alongside digga auger and auger drive accessories in the same catalogue. All of it is genuine hydraulic flow valve equipment made in Dyersville, Iowa.
Mounting position is worth a moment’s thought before you fit it. The valve is a serviceable item on the outside of the machine, so somewhere reachable, out of the swing path, and clear of where the stick passes trench walls will save it a hard life.
