Please Read: This specialty harness is designed to work with the SG-ASW-200 controller and allows you to add up to four extra control functions to your machine. It is built specifically for select Cat D Series loaders and is intended for operators who need expanded attachment control from a standard 14-pin connection.
Expanded Attachment Control: Once connected, this harness helps deliver up to 10 total functions, including two locking outputs, through an industry-standard wired 14-pin connector. It is an effective solution for applications that require more control options than the factory setup provides.
Added Output Functions:
Flexible Pin Configuration: The included pinning tool allows you to re-pin outputs for specialized operations, giving you more flexibility when setting up attachments or custom control requirements.
Machine Compatibility: This harness is designed specifically for Cat D Series 255 and 265 loaders equipped with a 14-pin connection. It is not intended for use with any other machine brand or model.
Cat D Series Notes: When using this adapter on compatible Cat machines, Pin K will not supply +12 volts because that pin is used by Cat as a ground-sense circuit for high-flow operation. Pin A is controlled through your switch panel rather than through the machine control system. A high-flow jumper is not installed.
Recommended Application: A common use for this harness is operating a grader with laser functions, such as certain 96-inch or 108-inch grader setups that require additional switched outputs.
This harness is a purpose-built solution for expanding attachment control on compatible Cat D Series machines while maintaining a clean and practical connection through the existing 14-pin system.
Technical Information: This harness is designed for use with the SG-ASW-200 controller and adds four additional control outputs through a 14-pin connector on compatible Cat D Series 255 and 265 loaders.
This harness is designed to work with the SG-ASW-200 controller to add up to four additional controls to a compatible machine.
This harness is made specifically for Cat D Series 255 and 265 loaders equipped with a 14-pin connection. It is not intended for other brands or machine models.
Yes. This harness is intended to be used together with the SG-ASW-200 controller in order to provide the added control functions.
When used as described, this setup can provide up to 10 functions in total, including two locking functions.
This harness adds outputs on pins L and M as latching functions, and pins G and H as momentary functions.
Yes. The outputs can be re-pinned for specialty operations by using the supplied pinning tool.
No. The description clearly states that this harness does not work with any other brand or model besides the specified Cat D Series machines.
No. On these Cat machines, pin K is used as a ground-sense circuit for high-flow operation, so it will not provide +12 volts.
Pin A is operated from the switch panel rather than from the machine’s native control.
A likely application for this harness is operating a grader with laser functions, such as a 96-inch or 108-inch Bobcat grader.
