Recommended flow
6–16 GPM
Torque @ 3,000 PSI
1,452 ft-lbs
Model
1DSS
Guaranteed Fit
Fast Shipping
Hassle-Free Returns
Description
Made in USA
5-yr warranty
Overview
This skid steer auger attachment package pairs the Digga 1DSS drive with the mount your machine needs, delivering 1,452 ft-lbs of torque at 3,000 PSI (1,691 ft-lbs maximum at 3,500 PSI) on machines flowing 6–16 GPM, and ships as a complete drilling package — drive unit, hoses, flush-face quick disconnects and mount. Two choices decide what you order: your Machine Type — skid steer, mini skid steer, mini excavator or tractor — and the Mount Package that matches it, because the mount is machine-specific and is not interchangeable between classes. Choosing mini excavator changes the drive’s published maximum drilling diameter in earth from 24" to 14", since a lighter carrier cannot deliver the same down-pressure. The 1DSS carries a 2" hex output shaft that fits every Digga A4 and RC4 auger bit, weighs 101 lbs, and can be converted to a screw anchor drive with Digga’s patented anti-kickback valve. HALO auger alignment is available as a factory-fitted option on any configuration.
Key Features of This Skid Steer Auger Attachment
- 1,452 ft-lbs @ 3,000 PSI | 1,691 ft-lbs max @ 3,500 PSI — for carriers flowing 6–16 GPM
- Compact high-torque Digga-manufactured gearbox — descends into the hole to maximise drilling depth without extensions
- Digga-designed Eaton Orbital Geroler motor with integrated pressure relief valve — eliminates bulky valve blocks and reduces leak points
- 2-piece shaft design — maximum side load rating without transferring load into the bearings
- TRU-CUT geometry — a 12" auger cuts a 12" hole, with no oversized holes to backfill
- 2" hex output shaft — fits the full Digga A4 and RC4 auger bit range
- Converts to a screw anchor drive with Digga’s patented anti-kickback valve
- HALO auger alignment available — factory-fitted LED plumb indication on any mount configuration
- Four machine classes, eight mount packages — one drive, correctly matched to your carrier
- 5-year gearbox / 3-year motor / lifetime shaft pull-out warranty — built in Dyersville, Iowa
Why Contractors Choose the 1DSS Package
- Buying the package removes the fitment guesswork — drive, hoses, flush-face disconnects and the correct machine-specific mount arrive matched, so there is no second order when the mount plate does not line up.
- The gearbox follows the bit down the hole — conventional drives keep the gearbox above the coupler, so usable depth is bit length minus drive height. Digga’s bell-motor layout recovers that height as drilling depth.
- TRU-CUT cutting geometry means less concrete per hole — an oversized hole is backfilled with concrete you paid for. A 12" bit cutting a true 12" hole is a direct materials saving on every pier.
- The integrated PRV removes the most common leak point — an external relief valve block adds four to six hydraulic connections, and every one is a potential failure.
- One drive covers a mixed fleet — the same 1DSS moves between a skid steer and a mini excavator by changing the mount rather than buying a second drive.
Digga 1DSS Auger Drive Specifications
| Specification | Value |
|---|---|
| Model | 1DSS |
| Torque @ 3,000 PSI | 1,452 ft-lbs |
| Max torque @ 3,500 PSI | 1,691 ft-lbs |
| Recommended flow | 6–16 GPM |
| Max pressure — do not exceed | 3,500 PSI @ 16 GPM |
| Max flow — do not exceed | 30 GPM @ 1,800 PSI |
| Max horsepower | 33 HP |
| Motor type | Orbital Geroler |
| Standard output shaft | 2" Hex |
| Recommended auger bits | A4 / RC4 |
| Weight | 101 lbs |
| Overall length | 24.5" |
| Diameter | 7.4" |
| HALO auger alignment | Optional |
| Warranty | 5-year gearbox / 3-year motor / lifetime shaft pull-out |
1DSS Drilling Capacity by Machine Type
| Machine Type | Digga machine class | Carrier weight range | Max drilling dia. (earth) |
|---|---|---|---|
| Skid Steer | Skid Steer Loader | 1-2.5T (2,200-5,500 lbs) | 24" |
| Mini Excavator | Mini Excavator | 0.75-3T (1,600-6,600 lbs) | 14" |
| Mini Skid Steer | Mini Loader | — | 24" |
| Tractor | Agricultural Loader | — | 24" |
Maximum drilling diameter differs by carrier class because down-pressure and machine stability differ — the drive itself is identical in every configuration. Where a carrier weight range shows a dash, Digga does not publish one for the 1DSS in that class — match the mount to your machine instead.
Choosing Your 1DSS Mount Package
| Mount Package | Fits | What it is |
|---|---|---|
| Universal Quick Attach Mount Package | Skid Steer | Standard SSQA mount plate with linkage — the common choice for full-size skid steers and compact track loaders |
| Universal Quick Attach Frame Package | Skid Steer | SSQA frame assembly with linkage and cradle for side-shift capability |
| Extension Frame (TPE) Package | Skid Steer | Telescopic piling and drilling extension frame for greater reach and depth |
| Slide Frame Package | Skid Steer / Tractor | Slide-shift frame allowing the drive to be offset laterally for drilling close to structures |
| Bobcat Mount Package | Mini Skid Steer | Mount built for the Bobcat MT series interface — not interchangeable with full-size SSQA |
| Single Pin Mount | Mini Excavator | Direct pin-on mount for single-pin excavator booms |
| Double Pin Mount | Mini Excavator | Two-pin excavator mount with linkage — the usual choice on mini excavators with a standard dipper |
| Bucket Mount Package | Tractor | Agricultural bucket side mount for tractor front-end loaders |
What Auger Bits Fit the 1DSS?
The 1DSS drives a 2" hex output shaft, which accepts the full Digga A4 general-purpose earth range and the RC4 rock/earth combination range, in diameters from 6" to 36". Digga XO20 outer extensions add depth in one-foot increments without buying longer bits. Auger bits and extensions are sold separately.
Which Machines Fit the Digga 1DSS Auger Package?
This package is available in four machine configurations — select the one that matches your carrier, as mounts are not interchangeable between classes:
Skid steer loaders and compact track loaders — Universal Quick Attach (SSQA), Frame, Extension Frame (TPE) or Slide Frame package. Digga rates this class at 1–2.5T (2,200–5,500 lbs).
Bobcat
Caterpillar
John Deere
Case
New Holland
Takeuchi
Kubota
Gehl
Mini skid steers and compact utility loaders — Bobcat Mount Package, built for the Bobcat MT series interface. Mini mounts do not fit full-size SSQA plates.
Mini excavators — Single Pin or Double Pin mount, pinned direct to the dipper. Digga rates this class at 0.75–3T (1,600–6,600 lbs). Pin diameter and spacing must match your machine.
Tractors — Agricultural Bucket Mount Package, which mounts to the side of a front-end loader bucket.
Every configuration requires an auxiliary hydraulic circuit supplying 6–16 GPM, and pressure must not exceed 3,500 PSI at 16 GPM. Add your machine make and model at checkout and we confirm the mount fits before the order ships — including pin sizing on the pin-on configurations.
Digga 1DSS Auger Package Questions, Answered
Which mount package do I need for my machine?
Match the mount to your machine class: a full-size skid steer or compact track loader takes the Universal Quick Attach, Frame, Extension Frame (TPE) or Slide Frame package; a Bobcat MT series mini loader takes the Bobcat Mount Package; a mini excavator takes the Single Pin or Double Pin mount; a tractor front-end loader takes the Bucket Mount Package. The mounts are machine-specific and cannot be swapped between classes.
What hydraulic flow does the Digga 1DSS need?
The 1DSS is rated for 6–16 GPM. Do not exceed 3,500 PSI at 16 GPM, or 30 GPM at 1,800 PSI. Machines flowing more than 16 GPM should step up to the 2DSS (10–26 GPM) or 3DSS (10–30 GPM).
Does the 1DSS need a case drain?
No. The 1DSS is a single-speed drive and runs on a standard two-line auxiliary circuit. Digga’s two-speed DDT drives are the models that require a case drain.
Why is maximum drilling diameter 24" on a skid steer but 14" on a mini excavator?
The drive is identical; the carrier is not. Digga publishes 24" maximum drilling diameter in earth for the 1DSS on a 1–2.5T skid steer and 14" on a 0.75–3T mini excavator, because a lighter machine cannot supply the down-pressure and stability a larger bit needs.
What is included in the package?
The 1DSS drive unit, hoses, flush-face quick disconnects and the mount package you select. Auger bits and extensions are sold separately — the drive takes any Digga A4 or RC4 bit with a 2" hex hub.
What is HALO and should I add it?
HALO is Digga’s LED auger alignment system, fitted into the hood of the drive. It shows green when the auger is plumb and red when it is not, guiding the operator back without a spotter. It is worth adding for fence lines, structural piers and any job where an out-of-plumb hole means rework or extra concrete. Select “Include HALO Auger Alignment System” to have it factory-fitted.
Can the 1DSS be used for screw anchors?
Yes, with Digga’s patented anti-kickback valve fitted. Using a DSS drive for anchoring without that valve voids the warranty.
What warranty comes with the 1DSS?
Five years on the gearbox, three years on the motor, and a lifetime shaft pull-out warranty. Warranty is subject to maintenance per the operator’s manual.
What auger bits should I buy with it?
A4 general-purpose bits for earth and clay, or RC4 rock/earth combination bits for mixed and fracturable ground. Both use the 2" hex hub the 1DSS drives. Bits run 6" to 36" in diameter — stay within the maximum drilling diameter published for your machine class.
Will this fit my machine?
Check three things: and it needs 6–16 GPM. Add your machine make and model at checkout and we confirm the fit before the order ships.
How is shipping calculated?
Shipping is calculated at checkout — add the item to your cart, enter your delivery address, and the shipping charge is shown before you complete your order. Lift gate service is available for residential deliveries and can be selected at checkout.
How do I order?
Add the item to your cart and check out online — the order page asks for your machine make and model, so there is no need to call ahead. We check the mount against your machine after the order and come back to you if anything needs changing. If you would rather ask first, email support@eskidsteer.com or use the chat button on your screen.
Buyers cross-shopping this package often compare it against a bare auger drive plus separate mount, or against a dedicated skid steer post hole digger. The package route wins on fitment certainty: the same 1DSS also configures as a mini excavator auger or a tractor auger attachment simply by changing the mount, so a mixed fleet runs one skid steer auger drive rather than three. Every configuration is genuine Digga auger equipment built in Dyersville, Iowa.
