Vendor: Blue Diamond
SKU: 108010-25
Availability: In stock
$865.99
$917.99
$865.99
Size: 36" Width - 15" Back Height - 4.43 cu ft
Subtotal: $865.99
Smooth Edge Mini Low Profile Bucket - Blue Diamond

Smooth Edge Mini Low Profile Bucket - Blue Diamond

$917.99 $865.99

Smooth Edge Mini Low Profile Bucket - Blue Diamond

$917.99 $865.99
Size: 36" Width - 15" Back Height - 4.43 cu ft
Overview

The mini low profile bucket is built for compact machines that need a durable, easy-loading attachment for dirt, gravel, mulch, feed, and general material handling. Designed to work with a wide range of mini skid steers, this bucket series combines strong construction with multiple sizing options to help operators match bucket capacity to machine size and job requirements.

Made from 3/16-inch A36 steel, these buckets are engineered for dependable everyday performance while maintaining a practical weight for compact equipment. The 25-inch bottom length depth supports efficient scooping and material retention, while the choice of smooth or tooth edges allows operators to select the configuration that best fits loose materials, light digging, or more aggressive ground engagement.

Available in 15-inch and 20-inch back heights, this mini low profile bucket lineup gives users flexibility across landscaping, construction, property maintenance, and agricultural applications. With a standard D-ring, optional bolt-on cutting edge for smooth models, and mount options for most mini skid steers, this bucket is designed for versatility and jobsite efficiency.

Key Features
  • 25-inch bottom length depth for efficient loading and material carry
  • Constructed from 3/16-inch A36 steel
  • Available with smooth edge or tooth edge options
  • Offered in 15-inch and 20-inch back heights
  • Standard D-ring included
  • Optional bolt-on cutting edge available for smooth-edge models
  • Mount options available to fit most mini skid steers
Benefits
  • Gives compact machines a dependable bucket for loading, carrying, and cleanup work
  • Offers multiple size and height options to better match machine capacity and job needs
  • Provides edge choices for smoother material handling or more aggressive digging performance
  • Supports long-term use with strong A36 steel construction
  • Adds flexibility with an optional bolt-on cutting edge on smooth models
  • Works well for landscaping, light construction, agriculture, and general property maintenance
Specifications
Feature Specification
Bottom Length Depth 25"
Material 3/16" A36 Steel
Edge Options Smooth or Tooth
Back Height Options 15" or 20"
Standard Feature D-Ring
Optional Feature Bolt-On Cutting Edge for Smooth Models
Mount Compatibility Available for Most Mini Skid Steers
Variant Specifications
Part Number Model Struck Cap. Weight
108010-25 36" Bucket, Low Profile, 15" Back Smooth 4.43 CU FT 181 lbs
108015-25 36" Bucket, Low Profile, 15" Back Tooth 4.43 CU FT 200 lbs
108020-25 42" Bucket, Low Profile, 15" Back Smooth 5.17 CU FT 225 lbs
108025-25 42" Bucket, Low Profile, 15" Back Tooth 5.17 CU FT 250 lbs
108030-25 44" Bucket, Low Profile, 15" Back Smooth 5.42 CU FT 255 lbs
108031-25 44" Bucket, Low Profile, 15" Back Tooth 5.42 CU FT 269 lbs
108040-25 48" Bucket, Low Profile, 15" Back Smooth 5.91 CU FT 275 lbs
108060-25 52" Bucket, Low Profile, 15" Back Smooth 6.00 CU FT 305 lbs
108065-25 52" Bucket, Low Profile, 15" Back Tooth 6.00 CU FT 315 lbs
108089-25 60" Bucket, Low Profile, 15" Back Smooth 6.83 CU FT 340 lbs
108095-25 60" Bucket, Low Profile, 15" Back Tooth 6.83 CU FT 373 lbs
108140-25 60" Bucket, Low Profile, Long Bottom, Smooth 6.83 CU FT 385 lbs
108012-25 36" Bucket, Low Profile, 20" Back Smooth 6.14 CU FT 249 lbs
108012-26 36" Bucket, Low Profile, 20" Back Smooth 6.14 CU FT 249 lbs
108017-25 36" Bucket, Low Profile, 20" Back Tooth 6.14 CU FT 250 lbs
108022-25 42" Bucket, Low Profile, 20" Back Smooth 7.16 CU FT 269 lbs
108027-25 42" Bucket, Low Profile, 20" Back Tooth 7.16 CU FT 279 lbs
108032-25 44" Bucket, Low Profile, 20" Back Smooth 7.50 CU FT 275 lbs
108032-26 44" Bucket, Low Profile, 20" Back Smooth 7.50 CU FT 246 lbs
108037-25 44" Bucket, Low Profile, 20" Back Tooth 7.50 CU FT 285 lbs
108037-26 44" Bucket, Low Profile, 20" Back Tooth 7.50 CU FT 247 lbs
108042-25 48" Bucket, Low Profile, 20" Back Smooth 8.19 CU FT 310 lbs
108047-25 48" Bucket, Low Profile, 20" Back Tooth 8.19 CU FT 320 lbs
108062-25 52" Bucket, Low Profile, 20" Back Smooth 8.87 CU FT 350 lbs
108062-26 52" Bucket, Low Profile, 20" Back Smooth 8.87 CU FT 300 lbs
108067-25 52" Bucket, Low Profile, 20" Back Tooth 8.87 CU FT 360 lbs
108090-25 60" Bucket, Low Profile, 20" Back Smooth 6.83 CU FT 334 lbs
Variant Options
Option Type Available Choices Details
Bucket Edge Smooth or Tooth Choose a smooth edge for standard material handling or a tooth edge for more aggressive digging and ground engagement.
Back Height 15" or 20" Select the bucket back height that best matches your machine size and the volume of material you plan to move.
Bucket Width 36" to 60" Multiple widths are available to help match bucket size to your mini skid steer and work environment.
Mount Style Most Mini Skid Steer Mounts Available Mount options are available for a wide range of mini skid steer platforms.
Attachment Compatibility

This mini low profile bucket is ideal for moving dirt, mulch, gravel, sand, feed, and general loose materials. It is well suited for landscaping, construction support, agriculture, cleanup work, and everyday compact equipment use.

Machine Compatibility

Compatible with most mini skid steers when ordered with the correct mount option. Always verify fitment, bucket sizing, and machine operating capacity before use.

FAQs

What material is this mini low profile bucket made from?
It is constructed from 3/16-inch A36 steel for dependable daily use.

What bucket edge options are available?
This bucket is available with either a smooth edge or a tooth edge, depending on the application.

What back heights are offered?
The bucket is available in both 15-inch and 20-inch back height versions.

Is a bolt-on cutting edge available?
Yes. Smooth-edge models can be ordered with an optional bolt-on cutting edge.

Does this bucket include a D-ring?
Yes. A D-ring comes standard on this bucket series.

What machines will this bucket fit?
Mount options are available to fit most mini skid steers.

Downloads

Contact eSkidSteer today to learn more or place your order! Visit eskidsteer.com, call us at 866-757-8337, email support@eskidsteer.com, or use the live chat button on the screen for immediate assistance.
