Description
📘 Overview
The Blue Diamond Smooth Edge Mini Low Profile Bucket is a smooth-edge mini skid steer bucket for scooping, loading, grading, and backdragging loose material with a clean finish. It mounts to a standard mini skid steer quick-attach plate, and its straight cutting edge leaves a smooth surface — ideal for final grading and handling material that's already broken up.
This listing covers the full smooth-edge range, so you can match width and capacity to your machine. Choose from 36", 42", 44", 48", 52", and 60" widths, each with a 15" or 20" back height — a taller back for more capacity, a shorter back to keep weight down on smaller carriers.
As a mini skid steer low profile bucket built from 3/16" A36 steel with a 25" bottom length, it handles daily loading without flexing. Operators choosing a blue diamond mini bucket want the smooth edge for grading and loose material; landscapers and site crews running a 48 inch mini skid steer bucket size it to their access and volume. Because Blue Diamond offers this mini low profile bucket smooth tooth edge in matched widths, many operators pair a smooth bucket for finish work with a tooth bucket for digging.
The low-profile design keeps the cutting edge in the operator's sightline for accurate grading and loading around obstacles.
⚙ Smooth Edge Mini Low Profile Bucket Features
- Smooth cutting edge for clean grading and backdragging
- Constructed of 3/16" A36 steel
- 25" bottom length depth
- Available in 36", 42", 44", 48", 52", and 60" widths
- 15" or 20" back height options
- Struck capacities from 4.43 to 8.87 cu ft
- Comes standard with D-ring
- Optional bolt-on cutting edge available
- Low-profile design for clear operator sightline
- Mounts available to fit most mini skid steers
🔑 Why Choose the Blue Diamond Smooth Edge Mini Low Profile Bucket
- Clean grading and backdragging — the smooth edge leaves a finished surface, where a tooth edge would gouge, making it the right choice for final grade and loose material.
- Widths to 60" for high volume — six widths, including a 60" model, let you move more loose material per pass on machines with the capacity for it.
- Two back heights for capacity control — 15" for lighter machines, 20" for up to 8.87 cu ft of material per scoop.
- 3/16" A36 steel construction — durable enough for daily loading, sized to survive real commercial use.
- Optional bolt-on cutting edge — add a replaceable edge to extend wear life in abrasive material.
📊 Mini Skid Steer Bucket Specifications
| Part Number | Configuration | Weight |
|---|---|---|
| 108010-25 | 36" Width - 15" Back Height - 4.43 cu ft | 181 lbs |
| 108020-25 | 42" Width - 15" Back Height - 5.17 cu ft | 225 lbs |
| 108030-25 | 44" Width - 15" Back Height - 5.42 cu ft | 200 lbs |
| 108040-25 | 48" Width - 15" Back Height - 5.91 cu ft | 275 lbs |
| 108060-25 | 52" Width - 15" Back Height - 6.00 cu ft | 195 lbs |
| 108095-25 | 60" Width - 15" Back Height - 6.83 cu ft | 373 lbs |
| 108012-25 | 36" Width - 20" Back Height - 5.53 cu ft | 249 lbs |
| 108012-26 | 36" Width - 20" Back Height - 5.53 cu ft | 249 lbs |
| 108022-25 | 42" Width - 20" Back Height - 7.16 cu ft | 269 lbs |
| 108032-25 | 44" Width - 20" Back Height - 7.5 cu ft | 275 lbs |
| 108032-26 | 44" Width - 20" Back Height - 7.5 cu ft | 275 lbs |
| 108042-25 | 48" Width - 20" Back Height - 8.19 cu ft | 310 lbs |
| 108062-25 | 52" Width - 20" Back Height - 8.87 cu ft | 300 lbs |
| 108062-26 | 52" Width - 20" Back Height - 8.87 cu ft | 300 lbs |
Struck capacities range from 4.43 cu ft (36", 15" back) to 8.87 cu ft (52", 20" back). All models are 3/16" A36 steel with a 25" bottom length and include a D-ring.
📋 Variant Options
Select your width and back height. The 15" back suits smaller carriers and lighter material; the 20" back carries substantially more per scoop. Widths from 36" to 60" let you match the bucket to your machine's capacity and your loading volume.
🚜 Machine Compatibility
Compatible with mini skid steers and compact tool carriers equipped with a mini universal (mini quick-attach) mount, including:
Bobcat MT
Ditch Witch
Vermeer
Toro Dingo
Boxer
Kubota
Compatibility is determined by mount type, not brand — confirm your machine's mini quick-attach configuration before ordering. Not sure it fits your carrier? Contact eskidsteer.com at (866) 757-8337.
❓ Frequently Asked Questions
Q: Smooth edge or tooth edge — which do I need?
Choose the smooth edge (this bucket) for grading, backdragging, and scooping loose material with a clean finish. Choose the tooth-edge version for digging into hard or rooty ground. Many operators run a smooth bucket for finish work and a tooth bucket for breaking ground.
Q: What width should I choose?
Match width to your machine's rated capacity and your access. Widths run 36" through 60". Wider buckets move more loose material per pass but weigh more loaded, so pair the 52"–60" models with larger minis and use 36"–44" on smaller carriers.
Q: What is the difference between 15" and 20" back height?
Back height sets capacity. A 15" back holds less and keeps weight down; a 20" back carries up to 8.87 cu ft for faster loading on machines that can lift it. Same footprint, more volume.
Q: Can I add a bolt-on cutting edge?
Yes — an optional bolt-on cutting edge is available. It adds a replaceable wear edge that extends the life of the bucket lip in abrasive material and can be swapped when worn.
Q: How is shipping calculated?
Shipping is calculated at checkout — add the item to your cart, enter your delivery address, and the shipping charge is displayed before you complete your order. Lift gate service is available for residential deliveries and can be selected at checkout.
Q: How do I order?
Add the item to your cart directly on eskidsteer.com and complete checkout online. Have your machine make, model, and serial number ready to confirm fitment before ordering. If you have a fitment question before purchasing, call us at (866) 757-8337.
