Description
🏭USA
💧Hydraulic
📘 Overview
This skid steer side discharge bucket — the Top Dog Dual Side Flow Bucket — mounts on a universal quick attach plate and discharges material out either side through a belt conveyor, turning a skid steer into a placement and feeding tool. The operator rotates and lowers the attachment to scoop, then rotates and raises it to become a spreader — flow direction and belt speed are both adjustable from dual control valves. Two build classes are offered and they are different machines: the heavy material versions (9000144, 9000145) run two belt motors, while the light material versions (9000144-72, 9000145-84) add a third motor driving a beater bar that prevents bridging in silage, feed and other light bulky material. All four run 15–20 GPM at 2,500 PSI.
A side discharge bucket occupies a narrow niche: it is a skid steer feeder bucket, a conveyor bucket attachment and a skid steer spreader bucket in one tool. Where a plain bucket dumps a heap you then have to spread, the belt places a metered ribbon exactly where you want it. As a material spreader attachment the light material models are the ones that handle silage and feed, because the beater bar is what stops bridging — the heavy models have no beater bar and will bridge on light bulky product.
⚙ Key Features of the Top Dog Attachments Dual Side Flow Bucket
- Discharges to either side — dual control valves select which side the belt runs to, so you place material without repositioning the machine.
- Adjustable belt speed — meter the discharge rate to the job — slow for precise placement, fast for spreading.
- Beater bar on light material models — a third orbit motor drives a beater bar that stops silage and feed bridging over the belt — the reason the light material version exists.
- 5/16" thick 2-ply asphalt belt — asphalt-grade belting survives abrasive material; a Chevron belt option is also available.
- Scoop and spread in one tool — rotate down to load, rotate up to discharge — no separate loader and spreader.
- 1" pillow block bearings, manually adjustable tensioners — belt tension is adjustable at four locations, so the belt can be trued rather than replaced when it drifts.
- Reaches where a spreader cannot — places material in barns, alleys and tight sites too small for a dedicated spreader or feeder truck.
🔑 Why Choose the Dual Side Flow Bucket?
- Feeds and places without repositioning — discharging either side means one pass down a feed alley does both sides of the barn.
- Light material models solve bridging — the beater bar keeps silage and feed moving onto the belt — without it, light bulky material arches over the opening and stops flowing.
- Meters the pour instead of dumping it — adjustable belt speed places a controlled ribbon of material rather than a heap you then have to spread.
- One machine covers loading and spreading — the same attachment scoops and discharges, so a skid steer replaces a loader plus a spreader on small operations.
📊 Top Dog Attachments Dual Side Flow Bucket Specifications
| Specification | Value |
|---|---|
| Flow Requirement | 15–20 GPM |
| PSI Min / Max | 2,500 PSI |
| Belt Motors | 4.9 cu. in. — dual motors |
| Belt | 5/16" thick, 2-ply asphalt belt (Chevron option available) |
| Belt Speed | Adjustable via dual control valves |
| Hydraulic Couplers | Flat face |
| Hydraulic Hoses | 1/2" |
| Bearings | 1" pillow block (2) |
| Cutting Edge | 5/8" x 6" |
| Mounting Plate | 5/16" |
| Bucket Thickness | 3/16" |
| Wear Bars | 3/8" |
| Tensioners | Manually adjustable at 4 locations |
| Country of Origin | Made in USA |
🔄 Dual Side Flow Bucket Sizes, Part Numbers and Weights
| Part # | Width | Material Class | Overall Width | Height | Struck Cap. | Heaped Cap. | Beater Bar | Weight |
|---|---|---|---|---|---|---|---|---|
| 9000144 | 72" | Heavy | 82" | 30" | 17.5 cu ft | 21 cu ft | No | 1,000 lbs |
| 9000145 | 84" | Heavy | 94" | 30" | 20.41 cu ft | 24.5 cu ft | No | 1,166 lbs |
| 9000144-72 | 72" | Light | 85" | 44" | 39.4 cu ft | 47.3 cu ft | Yes (18.6 cu in motor) | 1,157 lbs |
| 9000145-84 | 84" | Light | 97" | 44" | 46 cu ft | 55.2 cu ft | Yes (18.6 cu in motor) | 1,350 lbs |
🔗 What Is a Skid Steer Side Discharge Bucket Used For?
- Feeding silage and TMR down a barn alley
- Placing gravel and sand in tight access sites
- Backfilling trenches and along foundations
- Spreading topsoil and compost
- Bedding stalls and placing material where a spreader cannot reach
For barn feeding, measure your alley width against the 82"–97" overall widths before ordering — the bucket is wider than its nominal size.
🚜 Which Machines Fit the Dual Side Flow Bucket?
Compatible with skid steer loaders and compact track loaders equipped with a Universal Quick Attach (SSQA) system and an auxiliary hydraulic circuit, including:
BobcatCaterpillarJohn DeereCaseNew HollandTakeuchiKubotaGehl
Machine capacity: The side flow bucket weighs 1,000 to 1,350 lbs empty depending on width and material class. The host machine needs the rated operating capacity to carry that plus a full load out front.
The Dual Side Flow Bucket requires 15–20 GPM at 2,500 PSI to drive its belt motors. Most compact tractor loaders cannot supply this, so this attachment is specified for skid steers and compact track loaders. Compatibility is determined by mount type and available hydraulic flow, not by brand — confirm both your quick attach configuration and your machine’s flow and pressure rating before ordering.
❓ Dual Side Flow Bucket Questions, Answered
What is the difference between the light and heavy material side flow bucket?
The heavy material models (9000144 and 9000145) run two belt motors and are sized for dense material like gravel and sand — 17.5 and 20.41 cu ft struck. The light material models (9000144-72 and 9000145-84) add a third orbit motor driving a beater bar and carry far more volume — 39.4 and 46 cu ft struck — because light bulky material like silage needs capacity rather than weight capability.
What does the beater bar do?
The beater bar on the Top Dog light material side flow bucket prevents material bridging. Light bulky material such as silage or feed will arch over the belt opening and stop flowing; the beater bar keeps it moving down onto the conveyor.
What hydraulic flow does the side flow bucket need?
All Top Dog dual side flow bucket models require 15–20 GPM at 2,500 PSI. The light material models drive three orbit motors on that flow — two for the belt and one for the beater bar.
Can the bucket discharge to both sides?
Yes. The Top Dog dual side flow bucket discharges out either the right or left side opening, selected by dual control valves, which also set belt speed.
How does the bucket work as both a scoop and a spreader?
The operator rotates and lowers the attachment to scoop material up, then rotates and raises it so it becomes a spreader or feeder, with the belt carrying material out the chosen side.
What belt options are available?
The standard belt is 5/16" thick 2-ply asphalt belt. A Chevron belt is also offered — Chevron patterning grips better on inclined or slippery material.
Can the belt tension be adjusted?
Yes. The Top Dog side flow bucket has manually adjustable tensioners at four locations, running on 1" pillow block bearings, so belt tracking can be corrected rather than requiring belt replacement.
Will the side flow bucket work on a tractor loader?
This attachment requires 15–20 GPM of auxiliary hydraulic flow at 2,500 PSI, which most compact tractor loaders cannot supply. It is specified for skid steers and compact track loaders with an adequate auxiliary circuit. Confirm your machine’s flow and pressure rating before ordering.
How much does the side flow bucket weigh?
Weights range from 1,000 lbs for the 72" heavy material model to 1,350 lbs for the 84" light material model. The host machine needs the rated operating capacity to carry that plus a full load out front.
How is the side flow bucket shipped?
Shipping is calculated at checkout — add the item to your cart, enter your delivery address, and the shipping charge is displayed before you complete your order. These units ship LTL freight; lift gate service is available for residential deliveries and can be selected at checkout.
How do I order the dual side flow bucket?
Add the item to your cart directly on eskidsteer.com and complete checkout online. Select your width, belt and material class from the variant options, and have your machine make, model, serial number and hydraulic flow rating ready to confirm fitment before ordering. If you have a fitment question before purchasing, call us at (866) 757-8337.
