Description
📘 Overview
The Blue Diamond Severe Duty Series 3 Power Rake is a high-flow skid steer power rake built for the largest jobs and the toughest ground. It mounts to a universal skid steer interface and drives a carbide-toothed drum with a 6,000 Series hydraulic motor, leveling, grading, and conditioning soil while raking out rocks and debris.
This listing covers working widths from 84″ to 120″, all with replaceable carbide teeth standard. These are the widest power rakes in the line, matched to high-flow machines running 30–40 GPM.
As a blue diamond severe duty power rake series 3, it's built for commercial site prep at scale. An 84 96 120 inch power rake covers the largest lots and roadsides fast. Operators call it a skid steer harley rake 30 40 gpm for its high-flow drive; as a commercial power rake carbide teeth tool, the hardened teeth resist wear in rocky, abrasive ground and swap out individually.
Built on a 3/8″ thick-wall tube frame with airless tires, a 1.5″ motor shaft with high-pressure seals, and an 8″ drum (13″ including teeth), it requires 30–40 GPM and a case drain.
⚙ Severe Duty Series 3 Power Rake Features
- Available in 84″ to 120″ working widths
- 6,000 Series hydraulic motor
- Airless tires
- Replaceable carbide teeth come standard
- 3/8″ thick-wall tube frame
- 1.5″ motor shaft with high-pressure seals
- 8″ drum diameter, 13″ including teeth
- Recommended flow is 30–40 GPM
🔑 Why Choose the Blue Diamond Severe Duty Series 3 Power Rake
- Widths to 120″ for big jobs — the widest rakes in the line cover large lots and roadsides in fewer passes on high-flow machines.
- Carbide teeth standard — replaceable carbide teeth come standard, resisting wear in rocky ground and swapping out individually when worn.
- 6,000 Series motor for high flow — sized for 30–40 GPM machines to keep the wide drum turning through heavy soil.
- Airless tires — no flats to stop work on debris-strewn sites.
- 3/8″ thick-wall frame — severe-duty construction built to survive continuous commercial abuse.
🔄 Skid Steer Power Rake Variant Specifications
| Part Number | Width / Teeth | Weight |
|---|---|---|
| 332500 | 84" W/ Replaceable Teeth | 1257 lbs |
| 332502 | 96" W/ Replaceable Teeth | 1365 lbs |
🚜 Machine Compatibility
Compatible with skid steer loaders and compact track loaders equipped with a Universal Quick Attach system, including:
Bobcat
Caterpillar
John Deere
Case
New Holland
Takeuchi
Kubota
Gehl
Compatibility is determined by mount type, not brand — confirm your machine's quick attach configuration before ordering. It is designed for high-flow skid steers and compact track loaders with a universal quick-attach interface. It requires 30–40 GPM and a case drain — these are high-flow attachments, so confirm your machine delivers the flow before ordering. The wide 120″ model in particular needs a capable high-flow machine. Not sure it fits your machine? Contact eskidsteer.com at (866) 757-8337.
❓ Frequently Asked Questions
Q: How is the Series 3 different from the Series 2 power rake?
The Series 3 is the severe-duty, high-flow line — wider (84″–120″), with a 6,000 Series motor for 30–40 GPM machines and carbide teeth standard. The Series 2 covers narrower widths and lower flow. Choose Series 3 for large commercial jobs on high-flow machines.
Q: What hydraulic flow do I need?
It requires 30–40 GPM and a case drain. These are high-flow attachments, so a standard-flow machine won't run them properly. Confirm your machine's rated flow before ordering, especially for the wider models.
Q: Do the carbide teeth come standard?
Yes — replaceable carbide teeth are standard on the Series 3. They resist wear in rocky, abrasive ground far better than fixed teeth and swap out individually when worn, keeping long-term cost down.
Q: What width should I choose?
Widths run 84″ to 120″. Match to your machine's flow and your site size — the 120″ covers the most ground but demands a capable high-flow machine. For most high-flow skid steers, the 84″ or 96″ is the practical choice.
Q: How is shipping calculated?
Shipping is calculated at checkout — add the item to your cart, enter your delivery address, and the shipping charge is displayed before you complete your order. Lift gate service is available for residential deliveries and can be selected at checkout.
Q: How do I order?
Add the item to your cart directly on eskidsteer.com and complete checkout online. Have your machine make, model, and serial number ready to confirm fitment before ordering. If you have a fitment question before purchasing, call us at (866) 757-8337.
📥 Downloads
