Severe Duty Grapple Bucket | Blue Diamond

The Severe Duty Grapple Bucket is engineered for operators who need a high-capacity attachment for demanding material handling, cleanup, and bulk loading applications. Built for tough environments, this grapple bucket combines a rugged bucket body with powerful dual clamp control to help secure loose, uneven, and oversized materials with confidence.

Available in 72-inch, 78-inch, and 84-inch widths, this attachment is designed to handle demolition debris, recyclables, brush, wood waste, and industrial materials efficiently. Its large capacity, reinforced clamp system, and protected hydraulic routing make it well suited for jobs where durability and dependable gripping performance are essential.

With independent hydraulic clamps, heavy-duty top tines, and a wide grapple opening, this severe duty grapple bucket offers the control and strength needed for transfer stations, tree work, recycling operations, and high-volume cleanup tasks.

• Available in 72-inch, 78-inch, and 84-inch working widths
• Capacity options up to 14.04 cubic feet
• Bolt-on sides with punched edge for optional bolt-on cutting edges
• Dual independent hydraulic clamps for secure handling of uneven loads
• Reinforced cylinder covers for added hydraulic protection
• Protected hose routing designed to reduce pinch points
• Maximum grapple opening of 34 inches
• 3/4-inch thick steel top tines for long-term durability
• Greaseable 1-inch pivot pins for easier maintenance and longer service life
• Designed for machines rated at 50 HP and above
• Maximum hydraulic pressure of 2,500 PSI
• Flat face couplers included

• Helps secure loose, bulky, and irregular materials more effectively
• Improves handling control with dual independent clamp action
• Supports demanding cleanup and loading work with rugged steel construction
• Reduces hose damage risk with protected routing and covered cylinders
• Offers large bucket volume for moving more material in fewer passes
• Works well in harsh environments such as demolition, recycling, and wood processing

This severe duty grapple bucket is designed for high-volume material collection, loading, sorting, and cleanup. It is well suited for demolition waste, recyclables, transfer station materials, wood waste, brush, and industrial debris where secure clamping and bucket capacity are critical.

Compatible with skid steer loaders and similar machines rated at 50 HP and greater that can support the attachment’s hydraulic and lifting requirements. Always verify hydraulic pressure, coupler setup, and machine operating limits before use.

What is the maximum grapple opening on this bucket?
This severe duty grapple bucket offers a maximum grapple opening of 34 inches.

Are the clamps independent?
Yes. The attachment uses dual independent hydraulic clamps to improve control when handling uneven or irregular loads.

What machine size is recommended?
This grapple bucket is designed for machines rated at 50 horsepower and above.

Are the pivot pins serviceable?
Yes. It uses greaseable 1-inch pivot pins for easier maintenance and longer service life.

What kinds of jobs is this grapple bucket designed for?
It is ideal for demolition, recycling, transfer stations, tree work, wood processing, and industrial material handling applications.
