Description
Made in USA
12-mo warranty
Overview
This 2-way flow valve mounts to the motor inside the bail of the auger drive itself, rather than being bolted somewhere on your machine. That is the distinction from Digga’s external kits, and it carries one hard condition: it must be ordered at the same time as the drive. Once a drive has shipped, the integrated valve can no longer be fitted and the external kit is the only route. It suits DDS and DLS drives, and is not available on two-speed drives at all.
Key Features of the Integrated 2-Way Flow Valve for DDS & DLS Auger Drives
- Mounting: To the motor inside the bail (hood) of the auger drive
- Ordering condition: Must be ordered at the time of drive order — cannot be retrofitted
- Suits: DDS and DLS auger drives
- Not available on: 2-speed drives
- Ordered with the drive or not at all — the valve mounts inside the bail, so retrofitting after shipping is not possible.
- Nothing hanging off your machine — the valve travels with the drive rather than occupying space on the boom or stick.
- Unique to Digga, and available in 12V or 24V.
- Not available on 2-speed drives — those take the external kit if they need two-way flow at all.
- Extension harness in 3M, 6M, 12M or 15M to reach the cab.
- For DDS and DLS drives only.
Why the Integrated 2-Way Flow Valve Earns Its Place
- The integrated valve exists because a single-acting hammer circuit sends oil one way only. An auger needs it both ways — forward to drill, and reverse to back out of a hole it has bound itself into. Without two-way flow, an auger caught in clay or wrapped around a root becomes a problem you solve with the machine rather than the attachment.
- An integrated valve cannot be knocked off — it is inside the drive hood rather than strapped to a stick where it meets branches and trench walls.
- If you already own the drive, this is not your product — the external kit is, and it does the same job.
Integrated 2-Way Flow Valve for DDS & DLS Auger Drives Specifications
| Specification | Value |
|---|---|
| Mounting | To the motor inside the bail (hood) of the auger drive |
| Ordering condition | Must be ordered at the time of drive order — cannot be retrofitted |
| Suits | DDS and DLS auger drives |
| Not available on | 2-speed drives |
| Voltage | 12V or 24V — specified at order |
| Extension harness | 3M, 6M, 12M or 15M |
| Hoses | Not supplied — ordered separately |
Choosing Your Integrated 2-Way Flow Valve
Two decisions: the voltage of your machine, and how far the harness has to reach from the drive to the cab. Note the integrated kit uses metric harness lengths where the external kits are quoted in feet.
| Option | Choice | Notes |
|---|---|---|
| Voltage | 12V | Most compact equipment |
| Voltage | 24V | Larger excavators and many European machines |
| Extension | 3M | Shortest run — compact machines with the valve close to the cab |
| Extension | 6M | Typical for a mid-size excavator |
| Extension | 12M | Longer booms and larger machines |
| Extension | 15M | Maximum reach in the range |
Voltage
- 12V
- 24V
Extension Length
- 12M Extension
- 15M Extension
- 3M Extension
- 6M Extension
Which Machines Fit the Integrated 2-Way Flow Valve?
This valve suits DDS and DLS auger drives on machines with a single-acting hammer circuit and no two-way hydraulic flow. It cannot be fitted to a two-speed drive, and it cannot be added to a drive that has already shipped.
| Fitment factor | Requirement |
|---|---|
| Drive | DDS and DLS auger drives |
| Not compatible with | 2-speed (DDT) drives |
| Machine | Any carrier with a single-acting hammer circuit and no two-way flow |
| Electrical | 12V or 24V, specified at the time of order |
| Ordering | At the same time as the auger drive — not retrofittable |
| Hoses | Ordered separately |
Note your machine make and model at checkout and we confirm the Integrated 2-Way Flow Valve suits it before the order ships.
What to Order Alongside the Integrated 2-Way Flow Valve
- The auger drive itself — the valve is fitted to it at the factory, so both go on one order.
- Hydraulic hoses, which are not supplied with the valve.
- A cab switch — a joystick-mounted toggle or a floor-mounted foot switch, both separate items.
Integrated 2-Way Flow Valve for DDS & DLS Auger Drives Questions, Answered
Can I add this valve to a drive I already own?
No. The integrated valve mounts to the motor inside the bail of the drive and is fitted at the factory. Once a drive has shipped, Digga’s external 2-way flow valve kit is the way to get the same capability — it mounts to your machine instead.
Why is it not available on 2-speed drives?
Digga does not offer it on the 2-speed range. If you have a two-speed drive and need two-way flow, the external kit is the option.
12V or 24V — which do I need?
Match your machine’s electrical system. Most compact equipment is 12V; larger excavators and some European machines are 24V. Getting this wrong means the solenoid will not switch, so check the machine rather than guessing — it is not a tolerance the valve can absorb.
Which extension length should I pick?
Measure from where the valve mounts to where the switch will sit in the cab, then add slack for boom movement and a service loop. Running out of harness is a job stopper; a coil of spare harness is only untidy. On an excavator the boom articulates through more distance than people expect, so err longer.
How is the valve operated?
By a switch in the cab. Digga offers a joystick-mounted toggle switch and a floor-mounted foot switch as separate items, plus a 2-way flow controller. Which suits you depends on whether you would rather keep a hand free or a foot free while drilling.
Will this fit my machine?
Check three things: it is built for Any carrier with a single-acting hammer circuit and no two-way flow. Add your machine make and model at checkout and we confirm the fit before the order ships.
How is shipping calculated?
Shipping is calculated at checkout — add the item to your cart, enter your delivery address, and the shipping charge is shown before you complete your order. Lift gate service is available for residential deliveries and can be selected at checkout.
How do I order?
Add the item to your cart and check out online — the order page asks for your machine make and model, so there is no need to call ahead. We check the mount against your machine after the order and come back to you if anything needs changing. If you would rather ask first, email support@eskidsteer.com or use the chat button on your screen.
Buyers find the Integrated 2-Way Flow Valve searching for a auger drive valve, a flow reversal valve, or a excavator auger drive to suit a machine they already run. It sits alongside digga auger and auger drive accessories in the same catalogue. All of it is genuine hydraulic flow valve equipment made in Dyersville, Iowa.
The ordering condition is the thing to get right. Contractors regularly discover they want two-way flow after a few weeks of backing augers out by hand, by which point the integrated option has closed. If there is any chance you will want it, ordering it with the drive costs less than the external kit and puts nothing extra on the machine.
