Description
Made in USA 12-mo warranty
Overview
This skid steer broom attachment angles hydraulically from the cab rather than by hand at the attachment, and on a job where the angle changes often that is the entire argument for it. The manual version means climbing out, releasing the pivot and resetting it every time the direction of cast needs to change; the hydraulic version is a switch. Available in 72", 84" and 96" widths, angling 30 degrees left and right.
Key Features of the Hydraulic Pivot Angle Broom Attachment for Skid Steer
- Broom width: 72", 84" or 96"
- Swept width @ 15°: 69.55" / 81.14" / 92.73"
- Swept width @ 30°: 62.35" / 72.75" / 83.14"
- Overall width: 82" / 94" / 106"
- Angled from the cab — no climbing out to reset the pivot when the direction of cast changes.
- 30 degrees left and right, the same range as the manual version.
- Three widths from 72" to 96", at 1,063 to 1,182 lbs.
- Poly or poly/wire wafers, and optional jockey wheel and water kit.
- Floating design follows undulating ground for even contact and even wear.
- Quick-change core and wafers — wear is a consumable rather than a new core.
Why the Hydraulic Pivot Angle Broom Earns Its Place
- Angle changes constantly on real jobs — around parked cars, along kerbs, reversing direction at the end of a lane — and each manual reset is a minute plus getting out of the seat.
- Swept width narrows as you angle, so plan pass overlap from the angled figure rather than the nominal width.
- An electrical harness is needed to operate the pivot, which the manual version does not require.
Hydraulic Pivot Angle Broom Attachment for Skid Steer Specifications
| Specification | Value |
|---|---|
| Broom width | 72", 84" or 96" |
| Swept width @ 15° | 69.55" / 81.14" / 92.73" |
| Swept width @ 30° | 62.35" / 72.75" / 83.14" |
| Overall width | 82" / 94" / 106" |
| Depth | 77" |
| Height | 47" |
| Weight | 1,063 lbs / 1,115 lbs / 1,182 lbs |
| Max flow — do not exceed | 20 GPM |
| Max pressure — do not exceed | 2,250 PSI |
| Required flow | 8–20 GPM |
| Pivot | Hydraulic — angled from the cab |
| Wafers required | 36 (72"), 42 (84"), 48 (96") |
Choosing Your Hydraulic Pivot Angle Broom
Three decisions: the width, the brush type, and whether you add a jockey wheel, a water tank, or both.
| Option | Choice | Selected when |
|---|---|---|
| Brush Type | Poly Brush | General sweeping — loose dirt, gravel, leaves and light snow |
| Brush Type | Poly Wire Brush | Construction cleanup where packed dirt and dried mud need scarifying |
| Broom Width | 72" | Tighter sites and smaller carriers — 1,063 lbs |
| Broom Width | 84" | The general-purpose middle width at 1,115 lbs |
| Broom Width | 96" | Most coverage per pass at 1,182 lbs |
| Add-On | Add Jockey Wheel | Front caster holding a consistent sweep height on uneven ground |
| Add-On | Add Water Tank | Dust suppression in enclosed or occupied areas |
| Add-On | Add Jockey Wheel and Water Tank | Sustained municipal or indoor work where both apply |
Brush Type
- Poly Brush
- Poly Wire Brush
Broom Width
- 72"
- 84"
- 96"
Add Jockey Wheel or Water Tank
- Add Jockey Wheel
- Add Jockey Wheel and Water Tank
- Add Water Tank
- None
Which Machines Fit the Hydraulic Pivot Angle Broom?
Fits skid steer loaders and compact track loaders with a Universal Quick Attach (SSQA) interface, and needs an electrical connection to operate the hydraulic pivot.
| Fitment factor | Requirement |
|---|---|
| Machine interface | Universal skid steer quick attach (SSQA) |
| Auxiliary hydraulic flow | 8–20 GPM required |
| Max flow | 20 GPM — do not exceed |
| Max pressure | 2,250 PSI — do not exceed |
| Electrical | Required for the hydraulic pivot — harness options for 8-pin, 7-pin and 14-pin service plugs |
| Weight | 1,063 to 1,182 lbs depending on width |
| Side shift frame | Sold separately |
Bobcat Caterpillar John Deere Case New Holland Takeuchi Kubota Gehl
Note your machine make and model at checkout and we confirm the Hydraulic Pivot Angle Broom suits it before the order ships.
What to Order Alongside the Hydraulic Pivot Angle Broom
- An electrical harness or plug-and-play kit to operate the pivot — options exist for 8-pin, 7-pin and 14-pin service plugs, and a plug-and-play kit for machines with no service plug.
- Replacement wafers — 32" x 10" convoluted, 36 to 48 per unit depending on width.
- A side shift frame, which is sold separately.
Hydraulic Pivot Angle Broom Attachment for Skid Steer Questions, Answered
Hydraulic or manual pivot — is it worth the difference?
It depends entirely on how often you change angle. On a long straight run the manual version does the same job for less. On municipal work, car parks, or anywhere you reverse direction at the end of every pass, the hydraulic saves getting out of the cab each time — which adds up faster than most people expect.
Do I need an electrical connection?
Yes. The hydraulic pivot is switched electrically, so the broom needs a harness. Digga offers kits for machines with 8-pin, 7-pin and 14-pin service plugs, plus a plug-and-play kit with its own rocker switch for machines with no service plug at all.
How much does angling reduce the swept width?
More than most operators expect. At 30 degrees the 72" sweeps 62.35", the 84" sweeps 72.75" and the 96" sweeps 83.14". Plan overlap from those figures, not the nominal width.
What hydraulic flow does it need?
8–20 GPM. Do not exceed 20 GPM or 2,250 PSI — note that the pressure limit is lower than most auger attachments, so a high-pressure circuit needs checking.
How many wafers does it take?
36 on the 72", 42 on the 84" and 48 on the 96". Wafers are 32" x 10" convoluted in poly or poly/wire.
Will this fit my machine?
Check three things: it is built for Universal skid steer quick attach (SSQA); and it needs 8–20 GPM. Add your machine make and model at checkout and we confirm the fit before the order ships.
How is shipping calculated?
Shipping is calculated at checkout — add the item to your cart, enter your delivery address, and the shipping charge is shown before you complete your order. Lift gate service is available for residential deliveries and can be selected at checkout.
How do I order?
Add the item to your cart and check out online — the order page asks for your machine make and model, so there is no need to call ahead. We check the mount against your machine after the order and come back to you if anything needs changing. If you would rather ask first, email support@eskidsteer.com or use the chat button on your screen.
Buyers find the Hydraulic Pivot Angle Broom searching for a skid steer sweeper attachment, a angle broom skid steer, or a sweeper attachment to suit a machine they already run. It sits alongside hydraulic angle broom and skid steer attachments in the same catalogue. All of it is genuine digga broom equipment made in Dyersville, Iowa.
One figure worth checking against your machine: the maximum pressure is 2,250 PSI, which is lower than the 3,500 PSI most Digga auger attachments accept. A machine set up for high-pressure auger work may need its auxiliary circuit checked before running this broom.
