The Blue Diamond hydraulic breaker is engineered for powerful concrete demolition, asphalt removal, trench work, rock breaking, and heavy-duty construction applications. Designed to deliver reliable impact energy with fewer wear components, this skid steer breaker lineup offers a practical solution for contractors who need strong breaking performance with reduced maintenance demands.
Its mono-block design eliminates tie rods, helping improve structural durability while reducing the maintenance issues often associated with multi-piece breaker bodies. With only two internal moving parts, no re-gassing requirements, anti-blank firing protection, and self-regulating performance, these hydraulic breakers are built to maximize productivity while minimizing downtime in the field.
Available across a wide range of carrier sizes and energy classes, the Blue Diamond hydraulic breaker series is suited for compact equipment through larger skid steer and carrier platforms. Whether you are breaking reinforced concrete, removing pavement, trenching hard soil, or tackling general demolition work, this hydraulic hammer lineup is built for consistent power, long service life, and dependable jobsite performance.
| Feature | Specification |
|---|---|
| Warranty | 3 Years |
| Body Design | Mono-Block / No Tie Rods |
| Anti-Blank Firing System | Hydraulic Brake |
| Re-Gassing Requirement | Not Required |
| Internal Moving Parts | 2 |
| Stroke Control | 2 Speed / Variable Stroke |
| Operation | Quiet and Self-Regulating |
| Piston Protection | Body Bushings Around Piston |
| Part Number | Model | Working Pressure | Max Oil Flow | Frequency (BPM) | Operating Weight | Tool Diameter | Energy Class | Carrier Weight | (PSI) Back Pressure |
|---|---|---|---|---|---|---|---|---|---|
| 335005 | HB50 | 1,750 | 7 | 1,200 | 132 lbs | 1.5 | 100 | 1,500-2,650 lbs | 290-360 |
| 335009 | HB95 | 1,750 | 11 | 1,200 | 220 lbs | 1.8 | 200 | 2,650-4,000 lbs | 290-360 |
| 335016 | HB165 | 1,750 | 13 | 1,200 | 370 lbs | 2.2 | 400 | 4,000-6,600 lbs | 290-360 |
| 335021 | HB210 | 1,750 | 16 | 1,100 | 463 lbs | 2.5 | 500 | 6,100-9,900 lbs | 290-360 |
| 335030 | HB300 | 1,750 | 21.2 | 1,100 | 661 lbs | 2.9 | 700 | 8,800-15,500 lbs | 290-360 |
| 335040 | HB400 | 1,750 | 29.2 | 900 | 882 lbs | 3.1 | 1,000 | 13,500-20,900 lbs | 363 |
| 335053 | HB530 | 1,750 | 32 | 900 | 1,169 lbs | 3.3 | 1,200 | 17,650-25,350 lbs | 363 |
| Option Type | Available Choices | Details |
|---|---|---|
| Breaker Model | HB50 through HB530 | Select the breaker size that best matches your carrier weight, hydraulic flow, and jobsite demands. |
| Tool Style | Moil Point, Chisel, or Blunt Tool | Choose the tool that best fits the material and breaking application, from concentrated impact to broader surface breaking. |
| Energy Class | 100 to 1,200 | Multiple energy levels are available to support compact carriers through heavier-duty demolition equipment. |
This hydraulic breaker is ideal for concrete demolition, asphalt breaking, trenching through hard ground, rock reduction, utility work, road repair, and general construction demolition applications. The interchangeable tool options help tailor the breaker to different materials and breaking conditions.
Compatible with a wide range of carriers from 1,500 lbs up to 25,350 lbs depending on the selected breaker model. Always verify hydraulic flow, pressure, back pressure limits, carrier weight, and attachment fitment before operation.
What makes this hydraulic breaker different from many other models?
It features a mono-block design with no tie rods, no re-gassing requirement, and only two internal moving parts for simpler maintenance and long-term durability.
Does this breaker include anti-blank firing protection?
Yes. It includes an anti-blank firing system with hydraulic brake protection to help prevent internal damage when the tool is not properly loaded against a surface.
What tool options are available?
Tool options include a moil point, chisel tool, and blunt tool to match different demolition and breaking applications.
Is this breaker self-regulating?
Yes. The unit is designed to be self-regulating and also includes 2-speed control with variable stroke technology.
How quiet is the breaker during operation?
It is designed for quieter operation compared with many conventional breaker configurations, helping improve working conditions on the jobsite.
What size carriers can use these hydraulic breakers?
Depending on model selection, these breakers are designed for carriers ranging from 1,500 lbs up to 25,350 lbs.
