Mounting method
Universal Quick Attach
Construction
Grade 50 steel
Shaft
2.94" square
Guaranteed Fit
Fast Shipping
Hassle-Free Returns
Description
🏭Made in USA
📘 Overview
A skid steer attachment base with nothing to maintain. The EZ Spot UR Fixed Non-Rotating Base (EZ-001F) mounts any EZ Spot UR tool head to a skid steer without powered rotation. A 2.94 inch square shaft takes any head with a 3 inch square receiver, pinned with a 3/4 inch pin, and the head can be manually indexed 90 degrees on the shaft so an attachment runs horizontally or vertically as the job needs. With no moving parts to maintain and no rotation cylinders to service, it is the simplest and lightest way into the EZ Spot UR range — the right base when you lift and carry rather than place and tip.
⚙ Key Features of the Fixed Non-Rotating Base
- No moving parts to maintain — no rotation cylinders, no seals, nothing to service on the base itself.
- Manual 90 degree indexing — the tool head can be set horizontally or vertically on the shaft.
- 2.94" square shaft fitting any EZ Spot UR tool head with a 3" square receiver.
- Single 3/4" pin tool changes.
- Grade 50 steel, core welded.
- Lightest base in the range, leaving more machine capacity for the load.
- Ships with hoses, flush-faced couplers and a spring hose mount — note that, unlike the powered bases, no wiring harness is required because there is no rotation function to switch.
🔑 Why the Fixed Non-Rotating Base Earns Its Place
- Cheapest way into the EZ Spot UR range — the tool heads are the same, and the base can be upgraded later.
- Nothing to break — on a base with no rotation cylinders, there is no rotation function to fail mid-season.
- Keeps machine capacity for the load — less base weight means more of your rated operating capacity is usable.
- Still gives two working orientations through manual 90 degree indexing.
- Takes every tool head you own — the same receiver as the powered bases.
📊 Fixed Non-Rotating Base Specifications
| Specification | Value |
|---|---|
| Rotation | None powered; tool head indexes manually through 90° |
| Shaft | 2.94" square |
| Tool head interface | 3" square receiver, 3/4" pin |
| Moving parts | None |
| Construction | Grade 50 steel, core welded |
| Mounting method | Universal Quick Attach (customisable) |
| Supplied with | Hoses, flush-faced couplers, spring hose mount |
🔗 Which Tool Heads Fit the Fixed Non-Rotating Base?
The Fixed Non-Rotating Base accepts any EZ Spot UR tool head built with a 3" square female receiver — the common interface across the range. Heads change by pulling one 3/4" pin out of the shaft and sliding the next one on, so a single base serves every tool you own.
🚜 Which Machines Take This Skid Steer Attachment Base?
The Fixed Non-Rotating Base attaches to skid steer loaders and compact track loaders equipped with a Universal Quick Attach (SSQA) system, including:
BobcatCaterpillarJohn DeereCaseNew HollandTakeuchiKubotaGehl
Because the Fixed Non-Rotating Base has no powered rotation, it needs only the hydraulic supply for the tool head itself — typically 20–30 GPM at 3,000 psi through ¾" flush-face couplings. It can also be adapted to excavators, wheel loaders, telehandlers and backhoes with a special bolt-on mount.
Compatibility is determined by mount type, not brand — confirm your machine’s quick attach configuration and auxiliary hydraulic flow before ordering. Everything needed to confirm fitment is on this page — add it to your cart to check delivered pricing for your address.
Freight note: inspect the crate before signing the carrier’s Bill of Lading. Note any damage on the delivery paperwork at the time of delivery — that record is what supports a carrier claim.
❓ Fixed Non-Rotating Base Questions, Answered
Does the Fixed Non-Rotating Base rotate at all?
Not under hydraulic power. The tool head can be rotated manually through 90 degrees on the shaft and re-pinned, so the attachment can be run horizontally or vertically, but there is no powered rotation while working.
Why choose the fixed base over the Double Cylinder Rotating Base?
Three reasons: it costs less, it has no moving parts to maintain, and it weighs less, which leaves more of your machine's rated operating capacity for the load. If your work is lifting and carrying rather than placing and tipping, the rotation is not doing anything for you.
Can I fit a rotating base later?
Yes. Every EZ Spot UR tool head uses the same 3" square female receiver, so a head bought with the Fixed Non-Rotating Base will slide straight onto a Double Cylinder Rotating Base or Chain Rotating Base later.
Do I need a wiring harness with the Fixed Non-Rotating Base?
The base itself has no rotation function to switch, so it ships with hoses, flush-faced couplers and a spring hose mount rather than a harness. If your tool head has its own hydraulic function, that is supplied from the machine's auxiliary circuit as normal.
How is the Fixed Non-Rotating Base shipped?
Shipping is calculated at checkout — add the Fixed Non-Rotating Base to your cart, enter your delivery address, and the freight charge is displayed before you complete the order. Lift gate service is available for residential deliveries and can be selected at checkout.
