Vendor: Blue Diamond
SKU: 314002-25
Availability: In stock
$1,197.99
$1,270.99
$1,197.99
Size: 36” Tine Length
Subtotal: $1,197.99
Compact Mini Pallet Fork Loader Attachment | Blue Diamond

Compact Mini Pallet Fork Loader Attachment | Blue Diamond

$1,270.99 $1,197.99

Compact Mini Pallet Fork Loader Attachment | Blue Diamond

$1,270.99 $1,197.99
Size: 36” Tine Length
Overview

The Mini Pallet Forks are built for operators who need dependable lifting performance, durable construction, and excellent visibility for everyday material handling. Designed for compact equipment applications, these forks provide a practical solution for moving palletized loads, building supplies, feed, seed, and bundled materials with greater control.

Clear sight lines to the fork tips help improve placement accuracy and operator confidence, especially in tight work areas. Combined with a reinforced backrest, machined carriage bar, and rigid non-floating tine mounting, these mini pallet forks are engineered to deliver stable lifting performance across a wide range of jobs.

With multiple tine length options and a 3,000 lb rated capacity, this attachment offers a strong balance of versatility, durability, and ease of use for landscaping, farming, construction, and general property maintenance tasks.

Key Features
  • Engineered for strong visibility to the tine tips during operation
  • Heavy-duty design with Class 2 fork tines
  • Machined carriage bar for long-lasting strength and support
  • Adjustable tines lock securely in multiple positions
  • Non-floating tine mounting for a rigid and stable lift
  • Reinforced steel backrest for added durability
  • Available with 36-inch, 42-inch, and 48-inch tines
  • Rated lifting capacity of 3,000 lbs
Benefits
  • Improves load placement accuracy with better visibility to the fork tips
  • Handles a variety of pallet widths with adjustable tine positioning
  • Provides stable lifting performance with rigid tine mounting
  • Supports demanding work environments with reinforced steel construction
  • Offers multiple tine lengths to suit different applications and materials
  • Delivers reliable lifting strength for compact equipment users
Specifications
Feature Specification
Lift Capacity 3,000 lbs
Tine Type Class 2 fork tines
Tine Adjustment Multiple locking positions
Tine Mounting Non-floating
Backrest Reinforced steel
Available Tine Lengths 36", 42", and 48"
Carriage Bar Machined bar construction
Variant Specifications
Part Number Model Weight
314002 1 1/4" X 36” Tines, Pallet Fork 240 lbs
314001 1 1/4" X 42” Tines, Pallet Fork 313 lbs
314000 1 1/2" X 48” Tines, Pallet Fork 313 lbs
Variant Options
Option Type Available Choices Details
Tine Length 36", 42", or 48" Select the fork length that best fits your machine size and the materials you plan to move
Tine Thickness 1 1/4" or 1 1/2" Choose the tine size that matches your lifting application and expected load requirements
Tine Positioning Adjustable multiple positions Tines can be repositioned and locked to better fit different pallet widths and load sizes
Attachment Compatibility

These mini pallet forks are designed for compact material handling applications and are ideal for moving pallets, lumber, bagged goods, feed, seed, and bundled supplies in farms, construction sites, nurseries, and general maintenance environments.

Machine Compatibility

Compatible with mini machines and compact equipment that meet the attachment’s mounting and lifting requirements. Always verify your machine’s operating capacity and attachment fitment before use.

FAQs

What is the rated capacity of these mini pallet forks?
These pallet forks are rated for lifting up to 3,000 lbs.

What tine lengths are available?
The forks are available with 36-inch, 42-inch, and 48-inch tine options.

Are the tines adjustable?
Yes. The tines can be locked in multiple positions to fit different pallet and load widths.

What does non-floating tine mounting mean?
It means the tines are hooked securely at both the top and bottom to maintain a rigid and stable lifting setup.

Why is visibility to the tine tips important?
Clear visibility helps operators place loads more accurately and work more safely, especially in tighter spaces.

Downloads

Contact eSkidSteer today to learn more or place your order! Visit eskidsteer.com, call us at 866-757-8337, email support@eskidsteer.com, or use the live chat button on the screen for immediate assistance.
